SINAMICS G120 CU240E-2 PN 6SL3244-0BB12-1FA0
Unidad de control SINAMICS G120 CU240E-2 PN Tipo E Seguridad integrada STO PROFINET
6DI, 3DO, 2AI, 2AO, 1F-DI máximo Interfaz PTC/KTY Interfaz USB y SD/MMC
Protección IP20 Temperatura ambiente 0 a +50 °C Sin módulo de alimentación ni panel
Electrical data
Operating voltage via
The Power Module DC 24 V
External power supply DC 20 … 29 V
Max. power consumption 0.50 A
Power loss 5.50 W
Operating voltage via
The Power Module DC 24 V
External power supply DC 20 … 29 V
Max. power consumption 0.50 A
Power loss 5.50 W
Communication
Communication PROFINET, EtherNet/IP
Communication PROFINET, EtherNet/IP
Inputs / outputs
Standard digital inputs
Number 6
Switching level: 0→1 11 V
Switching level: 1→0 5 V
Fail-safe digital inputs
Number 1 (Use of 2 × DI Standard)
Digital outputs
as relay changer
Number 2
Analog / digital inputs
Number 2 (Differential input)
Analog outputs
Number 2 (Non-isolated output)
Standard digital inputs
Number 6
Switching level: 0→1 11 V
Switching level: 1→0 5 V
Fail-safe digital inputs
Number 1 (Use of 2 × DI Standard)
Digital outputs
as relay changer
Number 2
Analog / digital inputs
Number 2 (Differential input)
Analog outputs
Number 2 (Non-isolated output)
